Technical specifications
- Latching On/Off operation
- Key removal in both positions
- Keyed alike
- Supplied with 2 x Keys (KEY-FIS)
- Normal Voltage Rating: 230VAC 50Hz
- Contact Rating: Double Pole - 250VAC
- Fuse Rating: 4A Fast
- Legend (ON/OFF)
Features:
- When in OFF position the Red LED pulses and the internal fuse is disconnected from the supply
- When in ON/POWER position the Green LED lights up
- Cable tie points for secure installations
- Can only be switched by an authorised person
- Made in accordance with BS5839 Pt1 2013
- Surface mounted as standard, but can be flush fitted using a 35mm kobo box
FIREIS01
Technical specifications
- Latching On/Off operation
- Key removal in both positions
- Keyed alike
- Supplied with 2 x Keys (KEY-FIS)
- Normal Voltage Rating: 230VAC 50Hz
- Contact Rating: Double Pole - 250VAC
- Fuse Rating: 4A Fast
- Legend (ON/OFF)
Features:
- When in OFF position the Red LED pulses and the internal fuse is disconnected from the supply
- When in ON/POWER position the Green LED lights up
- Cable tie points for secure installations
- Can only be switched by an authorised person
- Made in accordance with BS5839 Pt1 2013
- Surface mounted as standard, but can be flush fitted using a 35mm kobo box
Dimensions:
90x90x55/45 (mm)
